Hydraulic truck cranes are different compared to other crane types due to the way they particularly operate. Hydraulic cranes utilize oil instead as opposed to using a winch in order to wind up cables to provide the lifting force. Since oil is a fluid that retains its volume, it is incompressible. Therefore, this means it is one of the most ideal types of fluids for pushing pistons towards the direction the force is going to be exerted.
The pressure generated by the hydraulic pump moves the piston. This action is maneuvered by the driver from the controls in his cab. Typically, hydraulic truck cranes utilize a pump which has 2 gears.
As the actual crane itself is mounted on a truck, it can travel numerous distances from site to site and there is little dismantling involved. The truck crane has a single engine that controls both the truck and the crane.
Other Parts
Boom Telescope: The boom telescope enables the boom to retract or extend because of hydraulics.
Jib: Jibs are latticed structure booms..
Boom Swing: Boom swings have a big roller or ball attached to the carrier. It can swing 360 degrees in both directions. Hydraulic mechanisms control the swing and provide swings at varying speeds in order to revolve the turntable gearbox.
Outrigger: The outrigger is a unit which helps the crane maintain its balance by utilizing hydraulics to lift the truck.
Load Movement Indicator: In order to warn the operator that maximum weight is approaching, the load movement indicator's lights flash.
Pump: The pump is the mechanism responsible for steering the outrigger.
Steel Cables: The steel cables are reinforced and run through the boom and the jib. They can generate up to 6350 kg or 14,000 lbs.
Boom Elevation: The crane's boom ascends with the use of double hydraulic cylinders that could be raised and lowered.
Rotex Gear: The rotex gear is situated under the cab and operated by hydraulics. It enables the boom to swivel on this gear.
