Terex Manlift Specifications
Terex is a Westport, Connecticut company that specializes in producing in manufacturing construction machines. Machines like aerial lifts, manlifts and boom lifts. These types of machines are designed to facilitate access to hard to reach areas, large equipment, buildings and roofs, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and includes steps or handholds or paltforms that are connected to the unit to be able to transport employees from each floor.
TB85
The TB85 by Terex provides a maximum working height of 91 feet. In addition, the platform's maximum height reaches 85 feet. This model's maximum width is 8 feet, 1 and 1/2 inches. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This model provides a reach of 70 feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is around 9 feet high by 8.5 feet wide by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, whilst the max working height measures at 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
